3D-Triangular Heat Sealing

Packaging Method3-Side Heat Sealing
Packaging MaterialsPaper, Laminated Film or Non-Woven Fabric and any suitable materials for heat sealing
Measurement MethodStandard: Rotary Doser Weighing
Option: Load-Cell Weigher, Auger Filler
Filling Volume10–35 CC (with Standard Doser)
(Depends on package size and measurement method)
Feeding Pitch55–150 mm
Filter Width80–240 mm by 20 mm
*need to change chute and sailor
Capacity30–80 bags/min
Dimensions1,275 (W) x 855 (D) x 1,810 (H) mm
Weight450 kg
Power Supply *3-Phase / 200 V / 4.0 kW
Compressed Air *300 L/min. (6 bar)
CE Marking **Not Available
* Transformer for local voltage and dried compressed air to be prepared by the customer.
** Fail-safe design based on CE directive.
